Li se tou pafwa yo rele Nasyonal tiyo fil, NPTF (F pou gaz), Ameriken Conic Standard, oswa tou senpleman "tiyo".
Kalite adaptè NPT: adaptè gason oswa fi
Pwodwi estanda: ISO 11926-3, SAE J514 ak BS 5200
Gwosè nan tablo gwosè NPT cartes se 1/8 NPT, 1/4 NPT, 3/8 NP, 1/2 NPT, 3/4 NPT, 1 "NPT elatriye.
Materyèl: asye kabòn, asye pur oswa alyaj kwiv
Fòm de NPT cartes Fitting: dwat, koud, Tee, Lakwa, redukteur elatriye.
Adaptè NPT ki apwopriye, adaptè metrik, adaptè bspp, adaptè SA, etc.
Adaptè 2NU9-LL 90 ° EXTRA LONG NPT MALE / NPSM pou adaptè fi 60 ° CONE jan sa a:
PAR T NON . | THREA D | DIMENSYON S | |||||
E | F | A | B | S 1 | S 2 | ||
2NU9-04L L | Z1 / 4 "X1 8 | 1/4 "X1 8 | 60. 2 | 4. 6 | 1 4 | 1 9 | |
2NU9-06L L | Z3 / 8 "X1 8 | 3/8 "X1 8 | 71. 4 | 6 | 1 9 | 2 2 | |
2NU9-08L L | Z1 / 2 "X1 4 | 1/2 "X1 4 | 82. 6 | 7. 5 | 2 2 | 2 7 | |
2NU9-12L L | Z3 / 4 "X1 4 | 3/4 "X1 4 | 91. 4 | 8. 9 | 2 7 | 3 2 | |
2NU9-16L L | Z1 "X11. 5 | 1 "X11. 5 | 108 | 10. 5 | 3 3 | 4 1 | |
2NU9-20L L | Z1.1 / 4 "X11. 5 | 1.1 / 4 "X11. 5 | 127 | 11. 2 | 4 1 | 5 0 | |
2NU9-24L L | Z1.1 / 2 "X11. 5 | 1.1./2"X11. 5 | 141 | 11. 2 | 4 8 | 5 5 | |
2NU9-32L L | Z2 "X11. 5 | 2 "X11. 5 | 168.4 | 11. 2 | 6 3 | 7 0 | |
