45 degre ekipman elbow, ki soti nan BSPT tiyo fil fini nan BSPP 60 degre konekte tib.
Materyel foje asye kabon.
Rankontre ISO 8434-6 ak BS 5200 estanda
5TB4-SP 45 ° BSPT GASON GASON / BSP FEMALE tiyo konekte tablo gwose jan swiv:
PATI NO. | Fil | DIMANSYON | |||||
E | F | Yon | B | S1 | |||
5TB4-02SP | R1 / 8"X28 | G1 / 8"X28 | 18 | 20 | 16 | ||
5TB4-04SP | R1 / 4 "X19 | G1 / 4 "X19 | 22 | 20 | 19 | ||
5TB4-06SP | R3 / 8"X19 | G3 / 8 "X19 | 25.5 | 23.5 | 24 | ||
5TB4-08SP | R1 / 2"X14 | G1 / 2"X14 | 31.5 | 27.5 | 30 | ||
5TB4-12SP | R3 / 4 "X14 | G3 / 4 "X14 | 32.5 | 31.5 | 33 | ||
5TB4-16SP | R1"X11 | G1"X11 | 42 | 37.5 | 41 | ||
5TB4-20SP | R1.1/4"X11 | G1.1/4"X11 | 45.5 | 40 | 48 | ||
