Kalite pwodwi: 1FO9-OG o bag figi sele ekipman tib
Nòm endistri yo: SAE J1453, ISO 8434-3, ISO 11926-2
Koneksyon E pou style F:
90 ° ORB KONPLETE O-RING / SAE O-RING BOSS S-SERI
Fòm: koud, dwat, Tee, Lakwa elatriye.
ORFS ekipman K ap travay Rating presyon: 3215 psi 5800 psi, 216 ba a 400 bar.
Flat Orfs o bag gwosè twous ak O bag figi konsepsyon sele nou menm tou nou ka ofri.
Diferans ant sele sou figi o ak sele bòs nan bag an
Materyèl Materyèl: kwiv; Kabòn asye; Asye pur
Aplikasyon: Ekipman Agrikilti, Pwosesis Otomobil, Transfè Chimik, Ekipman Konstriksyon, Transfè Gaz, Idwolik, Ekipman Manifakti, Marin, Manipilasyon Materyèl, Ekipman mobil, Petwòl, Emballage, Transpòtasyon
1FO9-OG 90 ° koud ORFS gason o-bag / sae o-bag bòs s-seri dimansyon dimansyon tablo tablo jan sa a:
PA RT N O. | T HR EA D | O OU | DIM E N S I O NS | ||||||
E | F | E | F | A | B | S 1 | S 2 | ||
1 FO 9 - 04 O G | 9/16 " X 18 | 7/16 " X 20 | O 011 | O 904 | 23 | 30.3 | 14 | 17 | |
1 FO 9 - 04 - 06 O G | 9/16 " X 18 | 9/16 " X 18 | O 011 | O 906 | 23 | 32 | 14 | 19 | |
1 FO 9 - 06 - 04 O G | 11/16 " X 16 | 7/16 " X 20 | O 012 | O 904 | 27.5 | 33.5 | 19 | 17 | |
1 FO 9 - 06 O G | 11/16 " X 16 | 9/16 " X 18 | O 012 | O 906 | 27.5 | 34.5 | 19 | 19 | |
1 FO 9 - 06 - 08 O G | 11/16 " X 16 | 3/4 " X 16 | O 012 | O 908 | 27.5 | 38 | 19 | 24 | |
1 FO 9 - 06 - 10 O G | 11/16 " X 16 | 7/8 " X 14 | O 012 | O 910 | 29 | 47 | 22 | 27 | |
1 FO 9 - 08 - 06 O G | 13/16 " X 16 | 9/16 " X 18 | O 014 | O 906 | 31 | 37 | 22 | 19 | |
1 FO 9 - 08 O G | 13/16 " X 16 | 3/4 " X 16 | O 014 | O 908 | 31 | 40.5 | 22 | 24 | |
1 FO 9 - 08 - 10 O G | 13/16 " X 16 | 7/8 " X 14 | O 014 | O 910 | 31 | 45.3 | 22 | 27 | |
1 FO 9 - 08 - 12 O G | 13/16 " X 16 | 1.1 / 16 " X 12 | O 014 | O 912 | 34.5 | 52 | 27 | 32 | |
1 FO 9 - 10 - 08 O G | 1 " X 14 | 3/4 " X 16 | O 016 | O 908 | 36.5 | 45 | 27 | 24 | |
1 FO 9-10 O G | 1 " X 14 | 7/8 " X 14 | O 016 | O 910 | 36.5 | 50.8 | 27 | 27 | |
1 FO 9 - 10 - 12 O G | 1 " X 14 | 1.1 / 16 " X 12 | O 016 | O 912 | 36.5 | 52 | 27 | 32 | |
1 FO 9 - 12 - 10 O G | 1.3 / 16 " X 12 | 7/8 " X 14 | O 018 | O 910 | 41 | 52.8 | 30 | 27 | |
1 FO 9 - 12 O G | 1.3 / 16 " X 12 | 1.1 / 16 " X 12 | O 018 | O 912 | 41 | 54 | 30 | 32 | |
1 FO 9 - 12 - 16 O G | 1.3 / 16 " X 12 | 1.5 / 16 " X 12 | O 018 | O 916 | 43 | 55.5 | 33 | 41 | |
1 FO 9 - 16 - 12 O G | 1.7 / 16 " X 12 | 1.1 / 16 " X 12 | O 021 | O 912 | 44.5 | 59 | 36 | 32 | |
1 FO 9 - 16 O G | 1.7 / 16 " X 12 | 1.5 / 16 " X 12 | O 021 | O 916 | 44.5 | 59 | 36 | 41 | |
1 FO 9 - 20 O G | 1.11 / 16 " X 12 | 1.5 / 8 " X 12 | O 025 | O 920 | 47.5 | 60.5 | 41 | 50 | |
1 FO 9 - 20 - 24 O G | 1.11 / 16 " X 12 | 1.7 / 8 " X 12 | O 025 | O 924 | 51.5 | 66.5 | 48 | 55 | |
1 FO 9 - 24 - 20 O G | 2 " X 12 | 1.5 / 8 " X 12 | O 029 | O 920 | 53.5 | 67.5 | 50 | 50 | |
1 FO 9 - 24 O G | 2 " X 12 | 1.7 / 8 " X 12 | O 029 | O 924 | 53.5 | 67.5 | 50 | 55 | |
F Mwen S O 11926 - 1 Remak F fen mwen s c onne c ted w i th I S O 11926 - 1po r t. | |||||||||
