Ekipman pip NPT dimansyon ak katalòg se menm bagay la soti nan founisè diferan.
Kalite materyèl ekipman tiyo tankou asye pur, kwiv ak plastik.
UK ak USA twous fil pip NPT aplikasyon nan ekipman tiyo ekipman ak ekipman tiyo endistriyèl.
Tiyo NPT cartouche cartouches pou priz soud, NPT fanm, SAE ORB, BSPT gason, ORFS gason, DIN 2353 tiyo connecteur, metrik o-bag elatriye.
Fòm nan adaptè tiyo NPT tankou dwat, koud, Tee, Lakwa, redukteur.
Nou menm tou nou ka bay jiska 2 pous bsp garnitur.
5GN BSP MAS O-RING / NPT ti fi Connector tiyo gwosè tablo tankou swiv:
PA RT N O. | T HR EA D | OU | DIM E N S I O NS | |||
E | F | E | A | L | S 1 | |
5 G N - 02 | G 1/8 " X 28 | Z 1/8 " X 27 | O 011 | 9.5 | 24.5 | 17 |
5 G N - 02 - 04 | G 1/8 " X 28 | Z 1/4 " X 18 | O 011 | 9.5 | 29.5 | 19 |
5 G N - 04 - 02 | G 1/4 " X 19 | Z 1/8 " X 27 | O 111 | 11 | 26 | 19 |
5 G N - 04 | G 1/4 " X 19 | Z 1/4 " X 18 | O 111 | 11 | 31 | 19 |
5 G N - 04 - 06 | G 1/4 " X 19 | Z 3/8 " X 18 | O 111 | 11 | 33 | 22 |
5 G N - 06 - 04 | G 3/8 " X 19 | Z 1/4 " X 18 | O 113 | 11.5 | 30 | 22 |
5 G N - 06 | G 3/8 " X 19 | Z 3/8 " X 18 | O 113 | 11.5 | 35 | 22 |
5 G N - 08 - 04 | G 1/2 " X 14 | Z 1/4 " X 18 | O 115 | 14 | 27 | 27 |
5 G N - 08 - 06 | G 1/2 " X 14 | Z 3/8 " X 18 | O 115 | 14 | 34 | 27 |
5 G N - 08 | G 1/2 " X 14 | Z 1/2 " X 14 | O 115 | 14 | 43 | 30 |
5 G N - 12 | G 3/4 " X 14 | Z 3/4 " X 14 | O 119 | 15.5 | 44.5 | 36 |
5 G N - 16 | G 1 " X 11 | Z 1 " X 11.5 | O 217 | 18 | 54.5 | 41 |
5 G N - 20 | G 1.1 / 4 " X 11 | Z 1.1 / 4 " X 11.5 | O 222 | 20 | 55.5 | 50 |
5 G N - 24 | G 1.1 / 2 " X 11 | Z 1.1 / 2 " X 11.5 | O 224 | 21.5 | 57 | 60 |
