Ekipman pip NPT dimansyon ak katalòg se menm bagay la soti nan founisè diferan.
Kalite materyèl nan ekipman tiyo tankou asye pur, kwiv ak plastik.
UK ak USA BSPP tiyo fil ekipman aplikasyon nan ekipman tiyo ekipman ak ekipman tiyo endistriyèl.
Tiyo NPT cartouche cartouches pou priz soud, NPT gason, SAE ORB, BSPT gason, ORFS gason, DIN 2353 tiyo connecteur, metrik o-bag elatriye.
Fòm nan adaptè tiyo BSPP tankou dwat, koud, Tee, Lakwa, redukteur.
1NL NPT gason / gason METRIC ak BONDED SEAL tiyo Connector gwosè tablo tankou swiv:
PATI NON. | FIL | SEA L | DIMANSYON | ||||
E | F | F | A | B | L | S1 | |
1NL-02-10 | Z1 / 8 "X27 | M10X1 | Z HD - 10 | 10.5 | 8 | 25.5 | 17 |
1NL-02-12 | Z1 / 8 "X27 | M12X1.5 | Z HD - 12 | 10.5 | 12 | 30 | 17 |
1NL-04-14 | Z1 / 4 "X18 | M14X1.5 | Z HD - 14 | 15 | 12 | 34.5 | 19 |
1NL-04-16 | Z1 / 4 "X18 | M16X1.5 | Z HD - 16 | 15 | 12 | 36.5 | 22 |
1NL-06-18 | Z3 / 8 "X18 | M18X1.5 | Z HD - 18 | 16 | 12 | 37.5 | 24 |
1NL-08-22 | Z1 / 2 "x14 | M22X1.5 | Z HD - 22 | 19.5 | 14 | 45 | 27 |
1NL-12-27 | Z3 / 4 "x14 | M27X2 | Z HD - 27 | 19.5 | 16 | 48.5 | 34 |
1NL-16-33 | Z1 "X11.5 | M33X2 | Z HD - 33 | 25.5 | 18 | 58.5 | 41 |
1NL-20-42 | Z1.1 / 4 "X11.5 | M42X2 | Z HD - 42 | 26.5 | 20 | 63.5 | 50 |
