Butt weld BSP ekipman Swivel
Kalite BSPP fil 60 ekipman kòn degre: avèk oswa san o-bag, gason oswa swviel Connector fanm.
Estanda nan katalòg BSPP ekipman ki baze sou ISO 8434-6 ak BS 5200.
Fil yo pou koneksyon an 60 kòn degre yo BSPP konfòme a ISO 228-1.
Koneksyon metalik tib pou pouvwa likid idwolik ak itilizasyon jeneral.
Jiayuan tou ka ofri Nerjaveèi asye BSP garnitur, kwiv bsp garnitur tiyo, bsp ekipman kawotchou elatriye.
2WB BUTT-WELD TUBE / BSP FEMENI 60 ° CONE dimensionnement Connector dimansyon jan sa a:
PA RT N O. | T HR EA D |
T U B E O .D. | DIM E N S I O NS | |||||
F | B | D | L | S 1 | ||||
2 W B - 10 - 04 | G 1/4 " X 19 | 10 | 5.5 | 10 | 35 | 19 | ||
2 W B - 14 - 06 | G 3/8 " X 19 | 14 | 6.3 | 14 | 40 | 22 | ||
2 W B - 18 - 08 | G 1/2 " X 14 | 18 | 7.5 | 18 | 50 | 27 | ||
2 W B - 22 - 08 | G 1/2 " X 14 | 22 | 7.5 | 22 | 50 | 27 | ||
2 W B - 22 - 12 | G 3/4 " X 14 | 22 | 10.9 | 22 | 62 | 32 | ||
2 W B - 28 - 16 | G 1 " X 11 | 28 | 11.7 | 28 | 65 | 41 | ||
2 W B - 34 - 20 | G 1.1 / 4 " X 11 | 34 | 11 | 34 | 68 | 50 | ||
2 W B - 42 - 20 | G 1.1 / 4 " X 11 | 42 | 11 | 42 | 59.5 | 50 | ||
2 W B - 50 - 24 | G 1.1 / 2 " X 11 | 50 | 13 | 50 | 57.5 | 55 | ||
